Shacman 4x2 16m3 side loading waste collection truck
Payment term: T/T, L/C , D/P
Delivery time: 25 Working days since get the Down payment.
After-sales service: For 1 year since leave factory
Shipping way: By container, RORO, Break bulk ship
Classification:
Share
Describe
| Item |
Shacman 4x2 16m3 side loading waste collection truck |
| Overall dimensions | 7000x2480x3500mm |
| Wheelbase | 4700 mm |
| GVW | 18000 KGS |
| Rated load | 10000 KGS |
| Kerb weight | 10500 KGS |
| Engine | Weichai engine,240hp, Diesel |
| Emission | Euro 5 |
| Transmission | Manual, 8 Forward speed+ 1 Reverse |
| Tire | 10.00R20, 6+1 |
| Steering | LHD/RHD |
| Garbage tank volume | 16 m3 |
| Garbage body material | Carbon steel |
| Garbage body thickness | Side & top panel: 4mm, Bottom panel: 5mm |
| Control method | Electric control and manual control |
| Lifting cylinder | Double - cylinder for lifting garbage tank |
| Rear door | Hydraulic unlocking and locking |
| Upper feeding port | Open or close controlled by lifting machine |
| Side hang up garbage bin | Matched with 240L, 660L standard bins |
| Equipment | Climb ladder, Compression function |
| Rated hydraulic pressure | 30Mpa |
